⎯ 293 ⎯
6 F 2 S 0 8 5 7
PTOF class
Attribute Name Attr. Type Explanation T M/O GRT100
LNName Shall be inherited from Logical-Node Class (see IEC 61850-7-2)
Data
Common Logical Node Information
LN shall inherit all Mandatory Data from Common Logical Node Class
M
OpCntRs INC Resetable operation counter O N
Status Information
Str ACD Start M Y
Op ACT Operate T M Y
BlkV SPS Blocked because of voltage O Y
Settings
StrVal
A
SG Start Value (frequency) O Y
BlkVal
A
SG Voltage Block Value O Y
OpDITmms ING Operate Delay Time O Y
RsDITmms ING Reset Delay Time O N
PTRC class
Attribute Name Attr. Type Explanation T M/O GRT100
LNName Shall be inherited from Logical-Node Class (see IEC 61850-7-2)
Data
Common Logical Node Information
LN shall inherit all Mandatory Data from Common Logical Node Class
M
OpCntRs INC Resetable operation counter O N
Status Information
Tr
A
CT Trip C Y
Op
A
CT Operate (combination of subscribed Op from protection functions) C N
Str
A
CD Sum of all starts of all connected Logical Nodes O N
Settings
TrMod ING Trip Mode O N
TrPlsTmms ING Trip Pulse Time O N
Condition C: At least one of the two status information (Tr, Op) shall be used.
