Appendix 1 Outline Drawings
Appendix 1.8 Manual Pulse Generator (HD60) Outline Drawing
77
Appendix 1.8 Manual Pulse Generator (HD60) Outline Drawing
Panel cut drawing
3 - Ø4.8 hole
Ø62
+2
0
Ø72 ± 0.2
Uniform
3-M4 stud bolts L10
8.89 7.60
12V0V A B
Rubber shield t2.0
3.6
16 24 27 ± 0.5
+12V 0V A B
Installation other than
M3 x 6 not possible
Ø77 ± 0.5
1
2
0
°
(
T
r
i
s
e
c
t
i
o
n
)
Ø80 ± 1
Ø60 ± 0.5
Ø60 ± 0.5
