Reference Manual
00809-0100-4665, Rev AA
August 2010
Rosemount 8732
4-6
Sensor Calibration Result
Displays the result of the sensor calibration verification test as pass or fail. For
more details on this parameter see Appendix C: Diagnostics.
Coil Circuit Result
Displays the result of the coil circuit test as pass or fail. For more details on
this parameter see Appendix C: Diagnostics.
Electrode Circuit Result
Displays the result of the electrode circuit test as pass or fail. For more details
on this parameter see Appendix C: Diagnostics.
Sensor Signature
The sensor signature describes the sensor characteristics to the transmitter
and is an integral part of the sensor meter verification test. From this menu
you can view the current stored signature, have the transmitter take and store
the sensor signature, and re-call the last saved good values for the sensor
signature. For more details on this parameter see Appendix C: Diagnostics.
Signature Values
Review the current values stored for the sensor signature. For more details on
this parameter see Appendix C: Diagnostics.
Coil Resistance
View the reference value for the coil resistance taken during the sensor
signature process.
Coil Signature
View the reference value for the coil signature taken during the sensor
signature process.
Electrode Resistance
View the reference value for the electrode resistance taken during the sensor
signature process.
Re-Signature Meter
Have the transmitter measure and store the sensor signature values. These
values will then be used as the baseline for the meter verification test. Use
this when connecting to older Rosemount or competitors’ sensors or installing
the magnetic flowmeter system for the first time. For more details on this
parameter see Appendix C: Diagnostics.
Recall Last Saved Values
Recalls the last saved “good” values for the sensor signature.
