HP DesignJet 5000 and 5500 Series Printers Service Manual
Service Tests and
Utilities
4
Introduction 4-2
Diagnostics - Self Test 4-2
The Printer hangs and nothing else happens 4-3
Error Memory Config:X 4-3
Error Memory Test 4-3
Power Supply Error #1 4-3
BootROM checksum failed 4-3
Boot Failed:1f500XX 4-4
Boot FAILED 4-4
BOOTROM ERROR: 4-4
COMPONENT MISMATCH: 4-4
Service Tests (Diagnostics) 4-5
Entering the Service Tests Menu 4-6
Scan Axis Test 4-9
Media Axis Test 4-11
Service Utilities 4-13
Entering the Service Utilities Menu 4-14
Turn DRIVE ROLLER 4-17
Prime TUBES 4-18
Altitude Setup 4-22
EEROM Setup 4-23
Reset Life Counters 4-28
Backup EEROM 4-30
Image Quality Warning 4-32
Diagnostic Print 4-33
Sleep Mode (DesignJet 5500 Series Only) 4-34
