Service Calibrations
5-5
HP DesignJet 5000 and 5500 Series Printers Service Manual
For Call Agents requesting the User to access a limited
number of Service Calibrations
a Once inside the "Printer Setup Options" menu and the "Device
setup" menu is highlighted, press the following key combination:
2 The message below is displayed. Select Ye s to continue.
3. You are now in the Service Menu. Use the Arrow keys to scroll to
the "Service Calibrations" menu and press the Enter key.
4. Use the Arrow keys to scroll through the "Service Calibrations"
selections. Press the Enter key to begin a specific operation when
the Service Calibration required is highlighted.
PH
O
N
E
S
U
U
PO
R
T
Printer setup options
Utilities...
I/O setup...
Internal RIP settings...
Queueing & Nesting...
HP-GL/2 settings...
Top
Enter
Back
n
p
Device setup...
Press Down
and Enter
Together
Warning!
Top
Enter
Back
n
p
Press Enter
This mode should NOT be
used without having the
guidance of a HP
representative person
Yes...
No
Service Tools
3 Service Tests...
Top
Enter
Back
n
p
Press Enter
Make Selection
1 Service Utilities...
2 Service Calibrations...
2 Service Calibrations...
2.2 Service Station
2.3 ACCURACY *
Top
Enter
Back
n
p
Press Enter
Make Selection
2.1 Scan axis
* This appears in the On-Site Repair Menu only.
