System Error Codes
2-18
HP DesignJet 5000 and 5500 Series Printers Service Manual
System Error: 0B000X
Problem
Description:
Unable to detect Fan (X = 7 - Vacuum, 8 - Cooling, 9 - Aerosol).
Corrective Action: Try the following:
Make sure that the Fan is connected correctly to the Main PCA.
Turn the Printer OFF and disconnect the Fan from the Main PCA.
Connect a
New
Fan to the Main PCA and power ON the Printer. If
the
New
Fan functions correctly without any Error Codes then
remove the
Old
Fan from the Printer and install the
New
one.
If the New Fan does not function correctly either, then replace the
Main PCA Page 8-81.
System Error: 0B0010 xxxxxxxx (Non-Continuable)
Problem
Description:
This firmware error code is related to the detection of the Printhead
cleaners by the line sensor. It always happens during initialization,
while checking the Printhead Cleaners. In most case, it is a problem
of incorrectly inserted Printhead Cleaners, but it can also be caused
by an incorrectly assembled Service Station.
Corrective Action: Try the following:
Remove the Printhead Cleaners and reinsert them again.
If the error still persists, perform the Service Station Calibration
Page 5-11.
If the error still persists, an onsite visit is necessary to repeat the
calibration or to change the Service Station assembly or the
Carriage Assembly.
System Error: 0B000A
Problem
Description:
Primer Shutdown Error.
Corrective Action: Try the following:
Check that the Service Station Cable (the grey flat cable with the
grey connector) is plugged into the Main PCA, and that the clips of
the connector are closed. Also check that the cable is not damaged.
Replace the Service Station Page 8-69.
