System Error: 0B000B
Problem
Description:
APS Failure.
Corrective Action: Try the following:
Check that the cable from the Ink Supply Station (ISS) PCA to
the Ink Supply Station is correctly connected.
Check that the Air Pressurization System Sensor Cable is
correctly connected and is NOT damaged.
Check all the tubes of the APS and make sure they are NOT
pinched or damaged.
Faulty APS. Replace the APS Page 8-67.
If the error code continues, replace the Main PCA Page 8-81.
System Error: 0B000C
Problem
Description:
Serial Device ADC test failure.
Corrective Action: Replace the Main PCA Page 8-81.
System Error: 0B000D
Problem
Description:
24 V source test failure.
Corrective Action: Replace the Main PCA Page 8-81.
System Error: 0B000E
Problem
Description:
At power-up, the Printer thinks it is smaller than 42 inches.
Corrective Action: Try the following:
Check that there are no obstacles in the Scan-Axis which stops
the Carriage from reaching the end-stops on both sides.
Check that the Carriage moves freely from side to side.
Check that the IDS Crane is installed correctly on top of the
Carriage and that the Carriage Cover is clipped on correctly.
