System Error Codes
2-13
HP DesignJet 5000 and 5500 Series Printers Service Manual
System Error: 0A0000
Problem
Description:
APS Failure.
Corrective Action: Try the following:
Check all the cables of the APS and make sure they are correctly
connected and are NOT damaged.
Check all the tubes of the APS and Tubes System and make sure
they are correctly connected and are NOT pinched or damaged.
Check that the Air Tube from the APS is correctly connected to
the Tubes System.
Replace ONE Ink Cartridge at a time, checking if the System
Error Code disappears.
Faulty APS. Replace the APS Page 8-67.
WARNING Only replace one component at a time and check if the error has
gone before replacing another component. Using this procedure
you will be able to determine exactly which component failed.
System Error: 0A0010
Problem
Description:
APS Failure.
Corrective Action: Refer to System Error Code 0A0000.
System Error: 0A0020
Problem
Description:
Error in Calibrating the APS Sensor.
Corrective Action: Try the following:
Check the APS Sensor and the valve cables, making sure that
they are NOT damaged and connected correctly.
Replace the APS ( Page 8-67) or the ISS PCA ( Page 8-91).
