Parts and Diagrams
7-8
HP DesignJet 5000 and 5500 Series Printers Service Manual
Left Hand Cover and Rear Door
Left Hand Cover and Rear Door
Reference
on
Drawing
HP Part Number Quantity Description/Comments
DJ 5000
Series
DJ 5500
Series
1 C6090-60039 1
Left Hand Cover (includes door)
2 0624-0771 4 Screw
3 0515-4268 1 Screw
4 C6090-60042 1 Left Hand Trim
5 0624-0771 1 Screw
6 0515-2248 1 Screw
7 C6090-60040 1 Rear Door
8 C6091-00139 Q1252-00003 1 Nameplate PS
C6095-00116 Q1251-00017 1 Nameplate RTL
9 C6090-60040 1 Left Hand Back Door
10 - 1 Adobe PS3 Logo
11 - 1 Pantone Certified Logo
OEM Logos
Reference
on
Drawing
HP Part Number Quantity Description/Comments
DJ 5000
Series
DJ 5500
Series
8 C6090-00235 - 1 Matchprint InkJet Proofer 5042
Nameplate
C6090-00220 - 1 Matchprint InkJet Proofer 5060
Nameplate
- - 1 Matchprint InkJet Proofer 5542
Nameplate
- - 1 Matchprint InkJet Proofer 5560
Nameplate
--1EagleJet
12 C6090-00244 1 HP Technology Logo
