Pinch-Wheel Cam
Removal
WARNING Switch off the Printer and remove the Power Cord.
NOTE Refer to the table on Page 8-4 for information on screw types.
1. Remove Right Rear Cover - Refer to
Page 8-16.
2. Remove Left Rear Cover - Refer to
Page 8-15.
3. Remove the Deflectors - Refer to Page
8-119.
4. Remove the Left Hand Cover - Refer
to Page 8-6.
5. Remove the Right Hand Cover - Refer
to Page 8-10.
6. Remove the Left Hand Trim - Refer to
Page 8-22.
7. Remove the Right Hand Trim - Refer
to Page 8-20.
8. Remove the Media Lever Assembly -
Refer to Page 8-18.
9. Remove the ISS - Refer to Page 8-64.
10. Remove the Service Station - Refer to
Page 8-69.
11. Remove the Vacuum Fan - Refer to
Page 8-103.
12. Remove the Electronics Module -
Refer to Page 8-97.
13. Remove the Booster Fan - Refer to
Page 8-108.
14. Remove the Media Sensor - Refer to
Page 8-109.
15. Remove the Entry Roller - Refer to
Page 8-111.
