Parts and Diagrams
7-6
HP DesignJet 5000 and 5500 Series Printers Service Manual
Right Hand Cover
Right Hand Cover
Reference
on
Drawing
HP Part Number Quantity Description/Comments
DJ 5000
Series
DJ 5500
Series
1 C6090-60038 1 Right Hand Cover (Includes
Front Panel Cable)
2 0624-0771 4 Screw
3 0515-4268 1 Screw
4 C6090-60043 1 Right Hand Trim (Includes Win-
dow and Lever Sensors)
5 0624-0771 1 Screw
6 0515-2248 1 Screw
7 C6090-60111 1 Front Panel Assembly (Includes
Front Panel Cable)
8 C6095-90021 Q1251-90011 1 Overlay (English)
C6095-90022 Q1251-90012 1 Overlay (Korean)
C6095-90023 Q1251-90013 1 Overlay (Taiwanese)
C6095-90024 Q1251-90014 1 Overlay (German)
C6095-90025 Q1251-90015 1 Overlay (French)
C6095-90026 Q1251-90016 1 Overlay (Spanish)
C6095-90027 Q1251-90017 1 Overlay (Italian)
C6095-90028 Q1251-90018 1 Overlay (Japanese)
C6095-90029 Q1251-90019 1 Overlay (Portuguese)
C6095-90030 Q1251-90020 1 Overlay (Chinese)
9 C6095-40065 1 Quick Reference Guide Holder
