Command Description Refer To
SYSTem:COMMunicate:SERial:FEED
<bool>|MIN|MAX|DEF
Sets the state of the serial port printing setting Section 8.4.9
SYSTem:COMMunicate:SERial:LINefeed?
[MIN|MAX|DEF]
Returns the state of the serial port linefeed setting Section 8.4.9
SYSTem:COMMunicate:SERial:LINefeed
<bool>|MIN|MAX|DEF
Sets the state of the serial port linefeed setting Section 8.4.9
SYSTem:COMMunicate:SERial:TIMe? [MIN|MAX|DEF] Returns the serial port sample period setting Section 8.4.9
SYSTem:COMMunicate:SERial:TIMe <num>
|MIN|MAX|DEF
Sets the serial port sample period setting Section 8.4.9
SYSTem:DATE? [MIN|MAX|DEF] Returns the date Section 8.4.10
SYSTem:DATE (<year>,<month>,<day>) Sets the date to the specified year, month, and day Section 8.4.10
SYSTem:ERRor? Returns a system error message from the system error
queue
Section 8.4.8
SYSTem:KLOCkout? [MIN|MAX|DEF] Returns the state of the keypad lockout Section 8.4.9
SYSTem:KLOCkout <bool>|MIN|MAX|DEF Enables or disables the keypad Section 8.4.9
SYSTem:PASSword:CDISable Disables password-protected commands Section 8.4.11
SYSTem:PASSword:CENable <pass> Enables password-protected commands Section 8.4.11
SYSTem:PASSword:CENable:STATe? Returns the current password-protection state Section 8.4.11
SYSTem:PASSword:CONVersion? [MIN|MAX|DEF] Returns the current password-protected state of the con-
version commands
Section 8.4.11
SYSTem:PASSword:CONVersion <bool> |MIN|MAX|DEF Sets the password-protection state of the conversion
commands
Section 8.4.11
SYSTem:PASSword:NEW <pass> Sets a new password Section 8.4.11
SYSTem:POWer:BATTery? Returns the current battery charge level Section 8.4.9
SYSTem:POWer:SOURce? Returns the source of power being used Section 8.4.9
SYSTem:SNUMber? Returns the instrument serial number Section 8.4.8
SYSTem:TIME? Returns the time Section 8.4.10
SYSTem:TIME (<hour>,<minute>,<second>) Sets the time to the specified hour, minute, second Section 8.4.10
SYSTem:VERSion? Returns the SCPI version number Section 8.4.8
TRIGger:TIMer? [MIN|MAX|DEF] Returns the value of the scan sequence timer setting Section 8.4.2
TRIGger:TIMer <num>|MIN|MAX|DEF Sets the scan sequence timer setting Section 8.4.2
UNIT:TEMPerature? Returns the system temperature units Section 8.4.8
UNIT:TEMPerature <unit> Sets the system temperature units Section 8.4.8
8.3.2 Command Syntax
The 1529 accepts commands that set parameters, execute functions or respond
with requested data. These commands are in the form of strings of ASCII-en
-
coded characters. As far as possible, the 1529 conforms to IEEE-488.2, 1992
and SCPI-1994. One notable exception is that compound commands are not al
-
lowed as explained below.
85
8 Digital Communications Interface
Interface Commands
