appear in this menu are COMM SETUP, DATE TIME, PASSWORD, CALI
-
BRATION, and SYSTEM RESET.
7.5.1 Comm Setup
The COMM SETUP function is used to setup the communication parameters
for the installed ports. Communications ports are used for communicating with
a computer, printer, or other equipment. When this function is selected, the bot-
tom portion of the display prompts the user to select the communication port to
setup. The 1529 thermometer readout is shipped standard with one serial
(RS-232) port and one IR port. A GPIB port may optionally be installed. The
GPIB port selection only appears if it is installed. ERRORS may also be se
-
lected for the port. This port selection allows the user to view any error mes
-
1529 Chub-E4 Thermometer Readout
User’s Guide
70
1
24.159C
3
24.142C
2
24.634C
4
24.015C
1529 HART 0.50 SERNUM
COMM
SETUP
DATE
TIME
PASS-
WORD
CALI-
BRATION
SYSTEM
RESET
EXIT
ENTER / MENU UNIT CONTRAST
1529
CHUB E-4 THERMOMETER READOUT
Figure 42 System Menu
