bottom portion of the display shows the current display settings. This function
is the same as the CHANNEL MODE menu DISPLAY OPTIONS function.
The RESOL parameter determines the number of decimal places (0 through 4
or AUTO) to be displayed for the temperature measurements. If AUTO is se-
lected, the instrument automatically determines the number of decimal places
to display depending on the conversion type.
The DECIMAL parameter is for selecting the character used as the decimal
separator. The choices are period (.) or comma (,).
The LAMP parameter specifies the brightness of the display (OFF, LOW,
MED, HIGH). Enabling this parameter causes the battery to discharge faster.
Press the LR buttons to select the parameter setting. Use the UD buttons
to scroll between the parameters. Press the Enter buttontosavethenewset
-
ting. Press the Exit buttontocancelandtoexittothemenu.
7.4 Logging Menu
The LOGGING menu provides functions for logging measurements on demand
and automatically, displaying log statistics, editing data labels, and resetting the
data labels to their default values. The submenus and functions that appear in
53
7 Menu Functions
Logging Menu
1
24.159C
3
24.142C
2
24.634C
4
24.015C
RESOL: 3
DECIMAL:
.
LAMP:
OFF
EXIT
ENTER / MENU UNIT CONTRAST
1529
CHUB E-4 THERMOMETER READOUT
Figure 24 Display Options
