both the demand and auto logs. When this function is selected, the bottom por
-
tion of the display shows the logging statistics.
The left side displays demand log statistics and the right side displays the auto
log statistics. The FILLED parameter shows the percentage of the total demand
or auto log memory that is currently filled. The FREE parameter shows the
number of readings remaining before the memory is full and the number of
readings currently stored in the demand or auto log memory. The COUNT pa-
rameter is only displayed when an auto log session is running. This parameter
shows the number of auto log readings remaining during the current log
session.
Press the Enter or Exit buttontoexitthisdisplayandtoreturntothe
LOGGING menu.
7.4.4 Data Labels
The DATA LABELS function allows 25 demand log and auto log labels to be
edited. When this function is selected, the bottom portion of the display allows
the user to select the data label to edit. The labels contain up to 8 alphanumeric
67
7 Menu Functions
Logging Menu
1
24.159C
3
24.142C
2
24.634C
4
24.015C
DEMAND LOG
FILLED: 4.0%
FREE: 95, 4
AUTO LOG
FILLED: 18.5%
FREE: 6654, 1506
COUNT: 6655
EXIT
ENTER / MENU UNIT CONTRAST
1529
CHUB E-4 THERMOMETER READOUT
Figure 39 Log Stats
