Note: The log is not started or stopped until the Enter buttonispressedtocon
-
firm the user action.
After a log session is started, the bottom portion of the display shows the log
statistics. These statistics can also be viewed from the LOG STATS function of
the LOGGING menu.
The left side displays demand log statistics and the right side displays the auto
log statistics. The FILLED parameter shows the percentage of the total demand
or auto log memory that is currently filled. The FREE parameter shows the
number of readings remaining before the memory is full and the number of
63
7 Menu Functions
Logging Menu
1
24.159C
3
24.142C
2
24.634C
4
24.015C
DEMAND LOG
FILLED: 4.0%
FREE: 95, 4
AUTO LOG
COUNT: 6494
FILLED: 18.5%
FREE: 6654, 1506
EXIT
ENTER / MENU UNIT CONTRAST
1529
CHUB E-4 THERMOMETER READOUT
Figure 34 Log Statistics (Auto Log Started)
1
24.159C
3
24.142C
24.634C
4
24.015C
START RECORDING DATA.
Press ENTER to continue...
2
EXIT
ENTER / MENU UNIT CONTRAST
1529
CHUB E-4 THERMOMETER READOUT
Figure 35 Start Stop
