and DISPLAY OPTIONS/AUTO-CAL. (The DISPLAY OPTIONS changes to
AUTO-CAL when the measure period is less than 1 second.)
7.1.1 Measure Period and Fast Measurement Mode
The MEASURE PERIOD function allows you to control the period (time) be-
tween measurements. You may select between 0.1, 0.2, 0.5, 1, 2, 5, 10 and 30
seconds, 1, 2, 5, 10, and 30 minutes, or 1 hour. Note: Accuracy may be reduced
in measurement periods less than one second. When this function is selected,
the bottom portion of the display shows the current setting and allows the set-
ting to be changed.
1529 Chub-E4 Thermometer Readout
User’s Guide
30
1
24.159C
3
24.142C
2
24.634C
4
24.015C
MEA PER: 1 SEC
EXIT
ENTER / MENU UNIT CONTRAST
1529
CHUB E-4 THERMOMETER READOUT
Figure 7 Measure Period
1
24.159C
3
24.142C
2
24.634C
4
24.015C
MEASUREMENT CONTROL FUNCTIONS
MEASURE
PERIOD
ENABLE
CHANNEL
CHANNEL
MODE
MOVING
AVERAGE
DISPLAY
OPTIONS
EXIT
ENTER / MENU UNIT CONTRAST
1529
CHUB E-4 THERMOMETER READOUT
Figure 8 Channel Menu
