of the display shows the current display settings. This function is the same as
the FIELDS menu DISPLAY OPTIONS function.
The RESOL parameter determines the number of decimal places (0 through 4
or AUTO) to be displayed for the temperature measurements. If AUTO is se-
lected, the instrument automatically determines the number of decimal places
to display depending on the probe conversion type.
The DECIMAL parameter is for selecting the character used as the decimal
separator. The choices are period (.) or comma (,).
The LAMP parameter specifies the brightness of the display (OFF, LOW,
MED, HIGH). Enabling this parameter causes the battery to discharge faster.
Use the LR buttons to change the parameter setting. Use the UD buttons
to scroll between the parameters. Press the Enter buttontosavethenewset
-
ting. Press and hold the Exit button to cancel to the main display or press the
EXIT button to cancel and to move to the next parameter.
When the AUTO-CAL function is selected, the following message is displayed.
FAST MODE AUTO CAL.
Press ENTER to continue...
Press the Enter button to perform the full measurement function. Press the
Exit buttontocancelandtoexittothemenu.
7.2 Probe Menu
The PROBE menu provides functions for specifying the channel, probe type,
the type of temperature conversion and coefficients, copying probe parameters,
35
7 Menu Functions
Probe Menu
1
24.159C
3
24.142C
2
24.634C
4
24.015C
RESOL: 3
DECIMAL:
.
LAMP:
OFF
EXIT
ENTER / MENU UNIT CONTRAST
1529
CHUB E-4 THERMOMETER READOUT
Figure 12 Display Options
