8.4.13 Statistical Calculation Types
The statistical calculation types are listed in the following table.
8.4.14 Field Types
The bottom portion of the main display is capable of showing up to eight fields.
These fields are selectable from the following table.
Number Keyword Field Type
0 ---- None
1DATEDate
2TIMETime
3 TYP Conversion Type
4 SER Probe Serial Number
5 INP Input
6 REF Reference
7 TEM Temperature
8 -T1 Delta Between Specified Channel and Channel 1
9 -T2 Delta Between Specified Channel and Channel 2
10 -T3 Delta Between Specified Channel and Channel 3
11 -T4 Delta Between Specified Channel and Channel 4
12 AVE Average
13 STD Standard Deviation
14 MIN Minimum
15 MAX Maximum
16 SPR Spread
17 STN Statistical n (Number of Measurements Comprising Statistics)
1529 Chub-E4 Thermometer Readout
User’s Guide
126
Number Type Keyword
1 Average AVE
2 Standard Deviation STD
3 Minimum MIN
4 Maximum MAX
5 Spread SPR
6 N (Number of Samples) STN
Table 4 Statistical Calculation Types
Table 5 Field Types
