testing conversion settings, viewing and printing probe parameters, and clearing
the default probe. The functions that appear in this menu are EDIT PROBE,
COPY PROBE, TEST PROBE, PRINT PROBE, and DEFAULT PROBE.
7.2.1 Edit Probe
The EDIT PROBE function allows you to select a probe channel, enter the
probe serial number, and select the conversion type and characterization coeffi-
cients and parameters. You select the probe channel from one of the four probe
channel setups or from one of the ten memory setups.
The EDIT PROBE function can be password protected to restrict access. See
Section 8.5.3, Password, for more information. If this function is password pro
-
tected, the user is prompted to enter the password to gain access. If an incorrect
password is entered, the display shows the message PASSWORD INCOR
-
RECT and access is denied. If the correct password is entered or if this function
is not password protected, the bottom portion of the display shows the probe
1529 Chub-E4 Thermometer Readout
User’s Guide
36
1
24.159C
3
24.142C
2
24.634C
4
24.015C
PROBE CHARACTERIZATION FUNCTIONS
EDIT
PROBE
COPY
PROBE
TEST
PROBE
PRINT
PROBE
DEFAULT
PROBE
EXIT
ENTER / MENU UNIT CONTRAST
1529
CHUB E-4 THERMOMETER READOUT
Figure 13 Probe Menu
