Instruction Manual
IB-106-340 Rev. 3.0
December 2003
Rosemount Analytical Inc. A Division of Emerson Process Management Installation 2-13
Oxymitter 4000
TYPE K
THERMOCOUPLE
SIGNAL
HEATER POWER
(BELOW COVER)
OXYGEN
SIGNAL
+
+
-
-
TERMINAL
BLOCK
GROUND
LUGS
37260052
LINE VOLTAGE
4-20 mA
SIGNAL
AC L1
AC N
+
+
-
-
4-20
TERMINAL
BLOCK
GROUND LUGS
1234 56
GRN
ORN
YEL
RED
BLK
BLK
BLU
ORN
YEL
RED
WHT
BLK
HTR
T/C
O
CELL
2
(BY FACTORY)
TO ELECTRONICS
FROM PROBE
BLU
ORN
RED
YEL
BLK
WHT
CALIBRATION
HANDSHAKE/
LOGIC I/O
PROBE
REMOTE
ELECTRONICS
TO IMPS 4000 IF USED.
REFER TO IMPS 4000
INSTRUCTION MANUAL.
LOGIC I/O +
LOGIC I/O -
LINE 1
NEUTRAL
GROUND
90-250 VAC, 50-60 HZ
LINE VOLTAGE INPUT
INTERCONNECTING
CABLE
4-20 mA +
4-20 mA -
GROUND
Figure 2-11. Electrical Installation – Oxymitter 4000 with Remote Electronics (Sheet 1 of 2)
