Instruction Manual
IB-106-340 Rev. 3.0
December 2003
Rosemount Analytical Inc. A Division of Emerson Process Management Installation 2-11
Oxymitter 4000
INTEGRAL ELECTRONICS
WITHOUT SPS 4000
LOGIC I/O/
CALIBRATION
HANDSHAKE
LINE VOLTAGE
4-20 mA
SIGNAL
AC L1
AC N
+
+
-
-
4-20
LOGIC I/O +
LOGIC I/O -
4-20 mA +
4-20 mA -
GROUND
CALIBRATION
HANDSHAKE
LINE 1
NEUTRAL
GROUND
90-250 VAC, 50-60 HZ
LINE VOLTAGE INPUT
TERMINAL
BLOCK
GROUND
LUGS
USER’S
SIGNAL
WIRING
CALIBRATION HANDSHAKE
REFER TO IMPS 4000
INSTRUCTION MANUAL
LINE 1
NEUTRAL
GROUND
90-250 VAC, 50-60 HZ
LINE VOLTAGE INPUT
INTEGRAL ELECTRONICS
WITH SPS 4000
INTEGRAL ELECTRONICS
WITH IMPS 4000
90-250 VAC, 50-60 HZ
LINE VOLTAGE INPUT
37260051
LINE 1
NEUTRAL
GROUND
CALIBRATION HANDSHAKE
REFER TO SPS 4000
INSTRUCTION MANUAL
4-20 mA +
4-20 mA
GROUND
Figure 2-10. Electrical Installation – Oxymitter 4000 with Integral Electronics
