Instruction Manual
IB-106-340 Rev. 3.0
December 2003
1-10 Description and Specifications Rosemount Analytical Inc. A Division of Emerson Process Management
Oxymitter 4000
MANIFOLD
INTERFACE
BOARD
CALIBRATION GAS 2
(LOW CALIBRATION GAS)
SOLENOID
CALIBRATION GAS 1
SOLENOID
(HIGH CALIBRATION GAS)
PRESSURE
SWITCH
POWER
SUPPLY BOARD
TERMINAL
COVER
CALIBRATION GAS
FLOWMETER
REFERENCE AIR
FLOWMETER
REFERENCE AIR
PRESSURE
REGULATOR
(OPTIONAL)
FRONT VIEW
REAR VIEW (OF MANIFOLD ONLY)
26170001
NOTES:
1. MANIFOLD COVER IS
REMOVED TO SHOW
INTERNAL COMPONENTS.
2. BOARD COMPONENTS
ARE NOT SHOWN FOR
CLARITY.
Figure 1-9. SPS 4000
