Reference Manual
00809-0100-4663, Rev BA
January 2010
B-3
Rosemount 8732
HAZARDOUS
LOCATIONS PRODUCT
APPROVALS OFFERING
The Rosemount 8700 Series magnetic flowmeters offer many different
hazardous locations certifications. The table below provides an overview of
the available hazardous area approval options. Equivalent hazardous
locations certifications for sensor and transmitter must match in integrally
mounted magnetic flowmeter systems. Remote mounted magnetic flowmeter
systems do not require matched hazardous location certifications. For
complete information about the hazardous area approval codes listed, see
Hazardous Location Certifications starting on page B-5.
Table B-1. Factory Mutual (FM)
Approvals Offering
Table B-2. Canadian Standards
Association (CSA) Approvals
Offering
Transmitter 8732E 8712D
(1)
(1) Remote Transmitter Only
8712H
(1)
Sensor 8705 8707 8711 8705 8707 8711 8707
FM Category Hazardous Area Approval Code
Non-Classified Locations
Transmitter NANANANANANA N0
Sensor NA N0 NA NA N0 NA N0
Suitable for Class I, Division 1
Explosion-Proof
Trans: Groups C, D T6 E5
(2)
(2) Available in line sizes 0.5 in. to 8 in. (15 mm to 200 mm) only
-E5- - - -
Sensor: Groups C, D T6 E5
(2)
- E5 - - - -
Explosion-Proof with Intrinsically Safe Output
Trans: Groups C, D T6 E5
(2)(3)
(3) For I.S. Output, Output Code B must be ordered
- E5
(3)
- - - -
Sensor: Groups C, D T6 E5
(2)
-E5- - - -
Suitable for Class I, Division 2
Non-Flammable Fluids
Trans: Groups A,B,C,D T4 N0 N0 N0 N0 N0 N0 N0
Sensor: Groups A,B,C,D T5 N0 N0
(4)
(4) 8707 Sensor has Temp Code - T3C
N0 N0 N0
(4)
N0 N0
(4)
Flammable Fluids
Trans: Groups A,B,C,D T4 N5 N5 N5 N5 N5 N5 N5
Sensor: Groups A,B,C,D T5 N5 N5
(4)
N5 N5 N5
(4)
N5 N5
(4)
Non-Flammable Fluids with Intrinsically Safe Output
Trans: Groups A,B,C,D T4 N0
(3)
N0
(3)
N0
(3)
- - - -
Sensor: Groups A,B,C,D T5 N0 N0
(4)
N0 - - - -
Other Certifications Product Certification Code
(5)
(5) Product Certification Codes are added to the Sensor model number only
European Pressure Equipment Directive (PED) PD - PD PD - PD -
NSF 61 Drinking Water
(6)
(6) Only available with PTFE (all line sizes) or Polyurethane (4 in. or larger) Lining Materials and
316L SST Electrodes
DW - DW DW - DW -
Transmitter 8732E 8712D
(1)
(1) Remote Transmitter Only
8712H
(1)
Sensor 8705 8707 8711 8705 8707 8711 8707
CSA Category Hazardous Area Approval Code
Non-Classified Locations
Transmitter NA - NA NA - NA -
Sensor NA - NA NA - NA -
Suitable for Class I, Division 2
Non-Flammable Fluids
Trans: Groups A,B,C,D T4 N0 N0 N0 N0 N0 N0 N0
Sensor: Groups A,B,C,D T5 N0 N0
(2)
(2) 8707 Sensor has Temp Code - T3C
N0 N0 N0
(2)
N0 N0
(2)
Other Certifications Product Certification Code
(3)
(3) Product Certification Codes are added to the Sensor model number only
European Pressure Equipment Directive (PED) PD - PD PD - PD -
NSF 61 Drinking Water
(4)
(4) Only available with PTFE (all line sizes) or Polyurethane (4 in. or larger) Lining Materials and
316L SST Electrodes
DW - DW DW - DW -
