7. ADJUSTMENT
BAS-311G, BAS-326G
106
5
Use 2 mm diameter pins (shaped like a needle) to align the holes in the X feed bracket (1) and the needle plate (2)
with the two holes in the home position reference plate (3), press the
or key to change the offset value (-999 –
999) in order to lower the needle to the home position.
• The feed mechanism will move in conjunction with the setting value.
Once the home position is aligned, tighten the two bolts (4) and remove the pins (shaped like a needle).
6
Press the RESET key.
• The feed mechanism will move to the home position.
Check the home position. Once the home position is
correctly aligned, remove the home position reference
plate (3).
7
Repeat steps 5 and 6 to adjust the home position.
8
End adjustment mode.
TEST indicator switches off
Press the TEST key.
• The display will return to the normal display and the
sewing machine will switch to home position detection
standby.
NOTE:
Always be sure to press the RESET key and check the home position before ending adjustment mode. If you end
adjustment mode without checking the home position, error "E202" may be generated.
5208Q 5276Q
