1594A/1595A Super-Thermometer
Using the Web Interface
68
1. In the NETWORK screen, use the Up/Down arrow keys to select HOST NAME.
2. While HOST NAME is highlighted, pressing the ENTER key opens the Alpha-Numeric Interface
allowing the user to enter a host name up to 16 characters in length.
3. Select the SAVE (F3) function key to save the newly entered host name.
4. Cycle the unit’s power to allow the new host name to take effect.
8.3 Using the Web Interface
The Super-Thermometer web interface (“Figure 17 Super-Thermometer Web Interface” on page 68) allows
the user to easily communicate with the Super-Thermometer through the Ethernet connection. The web inter-
face is a page that is served by the Super-Thermometer when the LAN port is congured and connected to a
network. The user is able to access the web interface by simply entering the IP address of the Super-Thermom-
eter in an internet browser.
Important: The LAN port must be properly congured and connected to a network before the web
interface tool will operate. The computer used to view the web interface must be on the same network.
The Home screen of the web interface displays product information and the current TCP/IP settings of the
Super-Thermometer.The Measure screen of the web interface provides a remote view of the Super-Thermom-
eter display with buttons and selection boxes that allow the user to start and stop measurement, reset statistics,
clear alert messages, enable and disable scan mode, and select measurement channels.
The Terminal screen of the web interface allows the user to enter any remote operation command in the
Command window. If a command requires a reply from the Super-Thermometer, the reply will appear in the
Response window. A password is required to use the Terminal screen. The default password is 1234. A new
password can be congured in the System Menu, Password screen.
Figure 17 Super-Thermometer Web Interface
8.4 Conguring the USB Port
The rear USB device port (Type B), labeled COMPUTER, allows the Super-Thermometer to be controlled by
a computer as a USB peripheral.
The USB port must be enabled before communication. Use the following steps to enable the rear USB port:
