Installation, Operation, and Maintenance Manual # 509252 Rev R 143
I300M/I310M Irradiator Parts List
Kit, reflector assembly, I300M, R500 (includes main reflector,
2 end reflectors and gaskets
— 292161
Kit, reflector assembly, I300M, R350 (includes main reflector,
2 end reflectors and gaskets)
— 292162
Kit, reflector assembly, I300M, dichroic (cold/R500)) (includes
dichroic main reflector, 2 R500 end reflectors and gaskets)
— 292163
Kit, reflector assembly, I300M, dichroic (cold/cold) (includes
main reflector, 2 end reflectors and gaskets)
— 292164
Kit, reflector assembly, I310M, R500 (includes main reflector,
2 end reflectors and gaskets) (for I31xM and I31xM-D series
irradiator only)
— 528795
Kit, reflector assembly, I310M, R350 (includes main reflector,
2 end reflectors and gaskets) (for I31xM and I31xM-D series
irradiator only)
— 528796
Kit, reflector assembly, I310M, dichroic (cold/R500) (includes
main reflector, 2 end reflectors and gaskets) (for I31xM and
I31xM-D series irradiator only)
— 528797
Kit, reflector assembly, I310M, dichroic (cold/cold) (includes
main reflector, 2 end reflectors and gaskets) (for I31xM and
I31xM-D series irradiator only)
— 528798
RF gasket (end reflector), 2 per lamp — 002521
Kit, RF gasket — 032932
Kit, RF gasket (for I31xM and I31xM-D series Irradiator only) — 514371
Kit, screen assembly replacement — 019712
Kit, switch, air pressure S201 292551
Kit, transformer, filament, 50/60 Hz T201A 036504
Photoresistor assembly (for I31xM series Irradiators) — 007971
Photoresistor assembly (for I31xM and I31xM-D series
Irradiators)
— 550582
Table 33. I300M/I310M Irradiator Parts List (continued)
Description
Reference
Designator Part Number
