Installation, Operation, and Maintenance Manual # 509252 Rev R 11
Introduction
This manual is designed to be used, not set aside until problems occur. The following
list of chapters and appendixes describes where to find information in this manual.
• This Introduction provides a brief description of the total system, and system
components. It also contains the Fusion UV Systems warranty policy and shipping
instructions for returning equipment.
• Chapter 1, “Safety,” contains important information! This chapter should be read
by all persons who will operate or troubleshoot system equipment.
• Chapter 2, “Mechanical Installation,” gives unpacking instructions, and
instructions for equipment placement, mounting, shielding and exhaust venting.
• Chapter 3, “Electrical System,” explains the power supply software setup,
including single and multiple unit programming and connections. HV capacitor
frequency tapping instructions are also provided.
• Chapter 4, “Operation,” describes steps for initial startup for both single and
multiple unit systems, how to operate master/slave and remote systems, and how
to reset the system after a fault. It also contains setup and operations instructions
for the Quick Restart Option (QRO).
• Chapter 5, “Troubleshooting,” consists mainly of information in table form. There
is a reference table for faults and indications, tables describing unit and system
fault indications, and a fault diagnosis table. The fault diagnosis table provides
faults, causes, and corrective actions.
• Chapter 6, “Maintenance,” covers routine maintenance and removal/replacement
instructions for the irradiator, power supply and modular blower. There is a
maintenance procedure page locator at the front of the chapter.
• Appendix A, “Specifications,” outlines the various characteristics of major
components of the F300S/F300SQ Ultraviolet Lamp System. It also lists agency
approvals and certificates for the relevant systems and components.
• Appendix B, “Cables and Connectors,” provides information on the interconnect
cables and system connector contact kits used with the F300S/F300SQ Ultraviolet
Lamp System.
