12 F300S/F300SQ Ultraviolet Lamp System
• Appendix C, “Outline Drawings,” contains drawings that provide overview details
for general reference for Fusion UV Systems products. These drawings are not to
be used in designing an installation; contact Fusion directly for current
specifications.
• Appendix D, “Lamp System Maintenance Log,” contains an example of a Fusion
UV Systems form to use for tracking lamp system maintenance.
• Appendix E, “Replacement Parts,” lists the various accessory replacement parts
available for Fusion UV Systems Irradiators.
• Appendix F, “Ignitor Bulb,” applies to lamps manufactured before July 1, 2002. It
describes the operation of the ignitor bulb that provides ignition to the main bulb.
• Appendix G, “Schematics,” contains figures that illustrate the various wiring
diagrams for Irradiator components.
Document Conventions
The products and components discussed in this document are designed and tested for
safe operation; however, they use technologies and resources that have inherent risks.
This section describes the conventions used throughout this manual when discussing
such technologies, so that users can plan and act accordingly when installing,
operating, or troubleshooting equipment.
Indications of Note, Caution, Warning, and Danger
Four categories of notice are indicated in this document; descriptions and examples of
their formatting are provided next.
NOTE: Notes serve to point out additional information about a subject or
process that is important, but not hazard-related.
CAUTION: Cautions generally indicate areas where a user should take
special care to avoid minor or moderate injury. It may also indicate
unsafe practices that could damage equipment or materials.
WARNING: Warnings indicate actions that can cause recoverable physical
harm; or destruction of equipment, data, or products.
