Installing the Software
31
2
G Follow the instructions on screen.
H Restart the Macintosh.
Note
Make sure to restart the compu-
ter. [ATM] will be completely in-
stalled only after restarting.
I Select [Control Panel] from the Ap-
ple menu, and then click [ATM].
J Open the ATM control panel.
Note
For more information about in-
stallation, see the User's Guide
in the ATM folder.
Installing screen fonts
A Start the Macintosh.
B Insert the CD-ROM into the CD-
ROM drive.
C Double-click the CD-ROM icon.
D Double-click the [Mac OS 8 and 9]
folder.
E Double-click the [Fonts] folder.
F Copy the fonts you want to install
into the [System] folder.
A confirmation dialog box ap-
pears.
G Click [OK].
The fonts are installed.
H Restart the Macintosh.
Reference
For information about installing
Printer Utility for Mac, see Post-
Script 3 Unit Type 2045 Operating
Instructions Supplement.
Mac OS X - Installing the
PostScript 3 Printer Driver
It is necessary to install a PPD file to
print from a Macintosh. Follow the
procedures to install a PPD file on
Macintosh running Mac OS X.
Printer driver is included in Mac OS.
When printing under Mac OS X
v10.1.x, use the printer driver includ-
ed in Mac OS.
Preparation
You need an administrator name
and a password (phrase). For more
information, consult your admin-
istrator.
A Insert the CD-ROM into the CD-
ROM drive.
B Double-click the CD-ROM icon.
C
Double-click the
[
Mac OS X
]
folder.
D Double-click the [PPD Installer]
folder, and then double-click the
installer icon.
E Follow the instructions on screen.
Setting up the PPD file
A Run Print Center.
B Click [Add Printer].
Note
Select [AppleTalk] in the first
pop-up menu.
If the zone has been set, select
the zone in the second pop-up
menu.
C Select the PPD file for the model
you are using from the [Printer
Model:] pop-up menu.
