0611 RM500SL User’s Guide Version 2.8 Page 22
5 Networking
5.1 Section overview
FastFacts 5.1: Networking
5.2 Networking requirements
FastFacts 5.2: Networking requirements
The RM500SL may be connected to a network using a Cat 5, RJ-45 cable. The
network connector is next to the serial number label on the recessed panel. For
automatic address assignment, the network must have a Dynamic Host
Configuration Protocol (DHCP) server.
For manual addressing, the remote computer must be running Windows 95 or
higher, File and Printer Sharing for Microsoft Networks must be enabled and the
TCP/IP Connection must be configured so that the IP address of the remote
computer is on the same subnet as the RM500SL. These settings should be
obtained from your network administrator.
The RM500SL may be connected to a network using a Cat 5, RJ-45 cable. This
allows screen images to be printed on a network printer or on a shared printer on
a networked PC. Images and underlying data may also be saved to a shared
folder on a networked PC. See 6: Printing and Storing Results for details. The
RM500SL may also be connected to a single computer using a network hub.
This section covers the following topics:
5.2: Networking requirements
5.3: Networking setup
5.4: Single computer connection
