Instruction Manual
IB-106-340CDR Original Issue
January, 2002
Rosemount Analytical Inc. A Division of Emerson Process Management Description and Specifications 1-7
Hazardous Area Oxymitter DR
Table 1-1. Product Matrix
OXT4ACDR Explosion Proof Oxymitter DR In Situ Oxygen Transmitter
Explosion Proof Exchange Probe - Instruction Book
Code Sensing Probe Type
1 Ceramic Diffusion Element Probe (ANSI 3 in. 150 lbs)
2 Snubber Diffusion Element Probe (ANSI 3 in. 150 lbs)
3 Ceramic Diffusion Element Probe (DIN 2572) - 1/4 in. Tube Fittings
4 Snubber Diffusion Element Probe (DIN 2572) - 1/4 in. Tube Fittings
5 Ceramic Diffusion Element Probe (JIS)
6 Snubber Diffusion Element Probe (JIS)
Code Probe Assembly
0 18 in. (457 mm) Probe
1 18 in. (457 mm) Probe with 3 ft (0.91 m) Bypass
2 18 in. (457 mm) Probe with Abrasive Shield
(1)
3 3 ft (0.91 m) Probe
4 3 ft (0.91 m) Probe with Abrasive Shield
(1)
5 6 ft (1.83 m) Probe
6 6 ft (1.83 m) Probe with Abrasive Shield
(1)
Code Mounting Hardware - Stack Side
0 No Mounting Hardware (“0” must be chosen under “Mounting Hardware - Probe Side” below)
1 New Installation - Square weld plate with studs
2 Mounting to Model 218 Mounting Plate (with Model 218 Shield Removed)
3 Competitor’s Mount
(2)
Code Mounting Hardware - Probe Side
0 No Mounting Hardware
1 Probe Only (ANSI) (N. American Std.)
2 New Bypass or Abrasive Shield (ANSI)
4 Probe Only (DIN) (European Std.)
5 New Bypass or Abrasive Shield (DIN)
7 Probe Only (JIS) (Japanese Std.)
8 New Bypass or Abrasive Shield (JIS)
Code Filtered Customer Termination - NEMA 4X, IP66
11 Standard Filtered Termination
12 Transient Protected Filtered Termination
OXT4ADR 3 2 1 1 11 Example
HIGH SULFUR SERVICE
For high sulfur applications, please add an additional line item to your purchase order requesting high sulfur cell part number 4847B63G02 in
lieu of the standard ZrO
2
cell.
Cell replacement kits for high sulfur service are also available.
NOTES:
(1)
Recommended usages: High velocity particulates in flue stream, installation within 11.5 ft (3.5 m) of soot blowers or heavy salt cake buildup.
Applications: Pulverized coal, recovery boilers, lime kiln.
(2)
Where possible, specify SPS number; otherwise, provide details of the existing mounting plate as follows:
Plate with studs Bolt circle diameter, number, and arrangement of studs, stud thread, stud height above mounting plate.
Plate without studs Bolt circle diameter, number, and arrangement of holes, thread, depth of stud mounting plate with accessories.
