Invacare Ranger II250 SERIES Wheelchair User Manual



35
PROCEDURE 10SHROUDS
S
H
R
O
U
D
S
FWD Wheelchairs (FIGURE 2)
REMOVING FRONT SHROUD.
1. Unclip the retaining strap securing the front shroud
and battery box to the wheelchair.
2. Feed the retaining strap through the front shroud.
3. Remove the front shroud from the wheelchair.
INSTALLING FRONT SHROUD.
1. Feed the retaining strap through the front shroud as
shown in FIGURE 2.
2. Position the bottom of the front shroud between the
battery box and the battery tray.
3. Clip the retaining strap together.
4. Pull end of retaining strap to secure front battery box
and front shroud in place.
REMOVING REAR SHROUD.
1. Perform one (1) of the following:
A. For 16,18, and 20-inch wide chairs:
l Unclip the retaining strap securing the rear
shroud and battery box to the wheelchair.
l Feed the retaining strap through the rear
shroud.
l Remove the rear shroud from the wheelchair.
B. For 14-inch wide chairs:
l Lift up on rear shroud and remove from wheel-
chair.
INSTALLING REAR SHROUD.
1. Perform one (1) of the following:
A. For 16,18, and 20-inch wide chairs:
l Feed the retaining strap through the rear
shroud as shown in FIGURE 2.
l Clip the retaining strap together.
l Press down on the rear shroud until the two
(2) clips secure the rear shroud to the two (2)
side shrouds.
l Pull end of retaining strap to secure rear bat-
tery box and shroud in place.
B. For 14-inch wide chairs:
l Algin clips of rear shroud with tabs on side
shrouds.
l Press down on rear shroud until the two clips
and dual lock fastener secure the rear shroud
in place.
REMOVING SIDE SHROUDS AND FILLERS.
1. Remove the front shroud from the wheelchair. Refer
to
REMOVING/INSTALLING FRONT SHROUD in this
procedure of the manual.
2. Remove the rear shroud from the wheelchair. Refer
to REMOVING/INSTALLING REAR SHROUD in this
procedure of the manual.
3. Perform one (1) of the following:
A. INTEGRATED SLING SEAT MODELS - Fold the
wheelchair. Refer to
TRANSPORTING RANGER
II FWD in PROCEDURE 12 of this manual.
B. CAPTAIN'S SEAT MODELS - Remove the
Captain's Seat from the wheelchair. Refer to
RE-
MOVING/INSTALLING CAPTAIN'S SEAT in PRO-
CEDURE 5 of the owner's manual, part number
1080722.
4. HIGH BACK CAPTAIN'S SEAT MODEL WHEEL-
CHAIRS ONLY (DETAIL "A") - Remove the phono jack
nut that secures the phono jack to the side shroud.
5. Remove the phillips screws, bolts, washers and lock-
nuts that secure side shroud and filler to the wheel-
chair frame. Refer to FIGURE 2 for phillips screw and
washer locations.
6. Remove side shroud and filler from the wheelchair.
7. Repeat STEPS 5-6 for the opposite side of the wheel-
chair, if necessary.
INSTALLING SIDE SHROUDS AND FILLERS.
1. Position side shroud and filler on the wheelchair frame.
2. Line up the mounting holes in the side shroud and
filler with the mounting holes in the wheelchair frame.
CAUTION
DO NOT overtighten the phillips screws
and phillips bolt that secure the side
shroud to the wheelchair frame - oth-
erwise damage to the side shroud can
occur.
3. Install the phillips screws, bolts, washers and lock-
nuts that secure the side shroud and filler to the wheel-
chair frame and tighten securely. DO NOT OVER-
TIGHTEN. Refer to FIGURE 2 for phillips screw, bolt,
washer and locknut locations.
4. Repeat STEPS 1-3 for the opposite side of the wheel-
chair, if necessary.
5. HIGH BACK CAPTAIN'S SEAT MODEL WHEEL-
CHAIRS ONLY - If necessary, perform the following:
A. Position the phono jack on the side shroud.
B. Reinstall the phono jack nut onto the phono jack
and tighten securely.
