SECTION 12—ACCESSORIES
Part No. 1143205 45 Lynx™L-3 & Lynx L-4
SECTION 12—ACCESSORIES
ƽ WARNING
After ANY adjustments, repair or service and before use, make sure that all
attaching hardware is tightened securely - otherwise injury or damage may result.
Before performing any maintenance, adjustment or service, turn power off and
remove key from ignition.
NOTE: The crutch/cane holder, safety flag, rear mounted basket and oxygen holder all install into
the accessory tubes; ONLY one of these may be installed at a time.
Installing/Removing the Accessory Tube
NOTE: For this procedure, refer to FIGURE 12.1.
Installing
1. Position the accessory tube onto the seat frame.
2. Secure the accessory tube to the seat frame using the mounting screw.
3. Remove the mounting knob from the accessory tube (Detail “A”).
4. Remove the cap from the accessory tube.
Removing
1. Remove the mounting screw securing the accessory tube to the seat frame.
2. Remove the accessory tube from the seat frame.
FIGURE 12.1 Installing/Removing the Accessory Tube
Mounting Screw
Accessory Tube
DETAIL “A”
Cap
Mounting
Knob
