190-00498-07 Rev A
Garmin G1000 Pilot’s Guide for Cessna Nav III
517
ADDITIONAL FEATURES
SYSTEM
OVERVIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO PANEL
& CNS
FLIGHT
MANAGEMENT
HAZARD
AVOIDANCE
AFCS
ADDITIONAL
FEATURES
APPENDICES INDEX
TheChartViewtimecriticalinformationcanalsobefoundontheAUX-SystemStatuspage.Thedatabase
CYCLEnumber,EXPIRES,andDISABLESdatesoftheChartViewsubscriptionappearineitherblueoryellow
text.WhentheChartViewEXPIRESdateisreached,ChartViewbecomesinoperative70dayslater.Thisis
shownastheDISABLESdate.WhentheDISABLESdateisreached,chartsarenolongeravailableforviewing.
The SHW CHRT Softkeylabelthenappearssubdued andis disableduntilarevisedissueof ChartViewis
installed.
NOTE
: A subdued softkey label indicates the function is disabled.
Press the MFD1 DB Softkey to place the cursor in the DATABASE window.  Scroll through the listed
information by turning the FMS Knob or pressing the ENTKeyuntiltheChartViewdatabaseinformationis
shown.
The ChartViewdatabasecyclenumbershowninthegure,1103,isdecipheredasfollows:
11–Indicatestheyear2011
03–IndicatesthethirdissueoftheChartViewdatabasefortheyear
TheEXPIRESdate17–FEB–11isthedatethatthisdatabaseshouldbereplacedwiththenextissue.
TheDISABLESdate28–APR–11isthedatethatthisdatabasebecomesinoperative.
Figure 8-46 AUX – System Status Page, ChartView Current and Available
ChartView
Data
The ChartView database is provided directly from Jeppesen.  Refer to Updating Jeppesen Databases in
AppendixBforinstructionsonrevisingtheChartViewdatabase.
