Garmin G1000 Pilot’s Guide for Cessna Nav III
97
AUDIO PANEL AND CNS
SYSTEM
OVERVIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO PANEL
& CNS
FLIGHT
MANAGEMENT
HAZARD
AVOIDANCE
AFCS
ADDITIONAL
FEATURES
APPENDICES INDEX
1
NAV VOL/ID Knob
– Controls NAV audio volume level. Press to turn the Morse code identifier audio on
and off. Volume level is shown in the NAV frequency field as a percentage.
2
NAV Frequency Transfer Key
– Transfers the standby and active NAV frequencies.
3
NAV Knob
– Tunes the standby frequencies for the NAV receiver (large knob for MHz; small knob for kHz).
Presstomovethetuningbox(lightbluebox)andFrequencyTransferArrowbetweenNAV1andNAV2.
4
NAV Frequency Box
–DisplaysNAVstandbyandactivefrequencyelds,volume,andstationID.The
frequency of the NAV radio selected for navigation is displayed in green.
5
COM Frequency Box
–DisplaysCOMstandbyandactivefrequencyeldsandvolume.TheselectedCOM
transceiver frequency is displayed in green.
6
COM Knob
– Tunes the standby frequencies for the COM transceiver (large knob for MHz; small knob for
kHz).Presstomovethetuningbox(lightbluebox)andFrequencyTransferArrowbetweenCOM1and
COM2.
7
COM Frequency Transfer Key
– Transfers the standby and active COM frequencies. Press and hold this key
fortwosecondstotunetheemergencyfrequency(121.500MHz)automaticallyintotheactivefrequency
field.
8
COM
VOL/SQ Knob
– Controls COM audio volume level. Press to turn the COM automatic squelch on
and off. Volume level is shown in the COM frequency field as a percentage.
9
DME Tuning Window
–DisplaysDMEfrequencypairingmode.DisplaybypressingtheDME Softkey.
10
ENT Key
–ValidatesorconrmsDMEpairingmodeandAuto-tuneselection.
11
FMS Knob
–FlightManagementSystemKnob,usedtoentertranspondercodes,selectDMEmodes,and
Auto-tuneentrieswhenDMETuningWindoworNRSTWindowispresent.PresstheFMS Knob to turn
the selection cursor on and off. The large knob moves the cursor in the window. The small knob selects
individual characters for the highlighted cursor location.
12
Transponder Data Box
– Indicates the selected transponder code, operating mode, reply, and ident status
for the transponder.
