HAZARD AVOIDANCE

TERRAIN-SVS ALERTS

AlertsareissuedwhenightconditionsmeetparametersthataresetwithinTerrain-SVSsoftwarealgorithms.

Terrain-SVSalertstypicallyemployaCAUTIONoraWARNINGalertseveritylevel,orboth.Whenanalertis

issued,visualannunciationsaredisplayedandauralalertsaresimultaneouslyissued.Table6-17showsTerrain-

SVSalerttypeswithcorrespondingannunciationsandauralmessages.

Whenanalertisissued,annunciationsappearonthePFDandMFD.TheTerrain-SVSAlertAnnunciationis

showntotheupperleftoftheAltimeteronthePFDandbelowtheTerrainLegendontheMFD.IftheTerrain-

SVSPageisnotdisplayedatthetime,apop-upalertappearsontheMFD.Toacknowledgethepop-upalert:

•PresstheCLR Key(returnstothecurrentlyviewedpage),or

•PresstheENT Key(accessestheTerrain-SVSPage)

Alert Annunciation

Figure 6-132 Terrain-SVS Alert Annunciations

Pop-up

Alert

Figure 6-133 Navigation Map Page

(After Terrain-SVS Pop-up Alert Acknowledgment)

Alert Annunciation

Terrain Legend

Terrain Display Enabled
