DME TUNING
NOTE: When another auxiliary window is turned on, the DME Tuning Window is replaced on the PFD.
NOTE: When turning on the G1000 for use, the system remembers the last frequency used for DME tuning
and the NAV1
,
NAV2,
or
HOLD
state prior to shutdown.
TheG1000SystemtunestheoptionalDMEtransceiver.TheUHFDMEfrequencyistunedbypairingwitha
VHFNAVfrequency.DMEfrequencypairingisautomaticandonlytheVHFNAVfrequencyisshown.
TheDMETuningWindowislocatedtotherightoftheHSIinthelowerrightcornerofthePFD.TheDME
transceiver istunedby selectingNAV1, NAV2, or HOLDinthe DMETuningWindow. Pressingthe
DME
SoftkeyswitchestheDMETuningWindowonandoff.
Figure 4-29 DME Tuning Window
DME
Modes
The following DMEtransceiverpairingscanbeselected:
•NAV1–PairstheDMEfrequencyfromtheselectedNAV1frequency.
•NAV2–PairstheDMEfrequencyfromtheselectedNAV2frequency.
•HOLD – When in the HOLD position, the DME frequency remains paired with the last selected NAV
frequency.
Selecting DME transceiver pairing:
1) Press the DME Softkey to display the DME Tuning Window.
2) Turn the small
FMS
Knob to select the DME tuning mode.
3) Press the
ENT
Key to complete the selection.
Pressing the CLR Key or FMSKnobwhileintheprocessofDMEpairingcancelsthetuningentryandreverts
backtothepreviouslyselectedDMEtuningstate.PressingtheFMS Knob activates/deactivates the cursor in
theDMETuningWindow.
SeetheFlightInstrumentsSectionfordisplayingtheDMEinformationwindow.
