64 Configuring PAD/ATPAD Ports
ATPAD Ports
Data Bits
Range: 7 to 8
Default: 8
Description: Number of bits per character when transmitting and receiving
data.
Boot Type: A Port boot is required for the change to take effect.
Parity
Range: NONE, SPAC, MARK, EVEN, ODD
Default: NONE
Description: The parity the port uses when transmitting and receiving data
NONE: No parity
SPAC: Space Parity
MARK: Mark Parity
EVEN: Even Parity
ODD: Odd Parity
Boot Type: A Port boot is required for the change to take effect.
Stop Bits
Range: 1, 1.5, 2
Default: 1
Description: The number of stop bits generated by the port when transmitting.
This parameter has no effect on data received by the port.
1 Stop Bit
1.5: 1.5 Stop Bits
2: 2 Stop Bits
Boot Type: A Port boot is required for the change to take effect.
Escape Character
Range: 0 to 255
Default: 43
Description: Specifies the character used to escape the Command Mode.
Boot Type: A Port boot is required for the change to take effect.
