Configuring PAD/ATPAD Ports 53
Detailed PAD Port Statistics
Detailed PAD Port Statistics
Function
When you select Detailed PAD Port Statistics, a series of screens appears that
provides information about the state and status of a PAD port.
What You See in
the First Screen
Figure 9 shows the first screen of the Detailed PAD Port Statistics.
Figure 9. Example of Detailed PAD Port Statistics, First Screen
Description of
Terms — First
Screen
The first Detailed PAD Port Statistics screen contains this information:
Node: Address: Date: Time:
Detailed PAD Statistics: Port 3 Page: 1 of 3
Port Number: 3 Port Type: ASYNC PAD Port Status: Up
Port Speed: 9600 Port State: X28
Port Utilization In: 0% Port Utilization Out: 0%
Physical:
Parity Errors: 0 Overrun Errors: 0 Framing Errors: 0
Data Summary:
IN OUT IN OUT
Characters: 0 0 Characters/sec: 0 0
Packets: 0 0 Packets/sec: 0 0
Number of Packets Queued: 0
EIA Summary: INPUT OUTPUT
DTR RTS MB P14 DSR DCD RI CTS
State: Connected (SIMPLE) L L L L H H L H
Press any key to continue (ESC to exit)...
Screen Term Tells You...
Port Number Number of the port
Port Type Type of port: ASYNC PAD
Port Status Status of the port: Up
Port Speed The configured port speed
Port State These are the possible states:
• X.28: The port is in Command mode
• PAD: The port is in Data mode
Port Utilization: IN/OUT Percentage of port bandwidth being used
Physical Number of Parity, Overrun, and Framing
errors since the last reset
