1-4
Instruction Manual
IM-106-4050 Original Issue
March 2006
OxyBalance Oxygen Display
and Averaging System
Signal Pass Through Terminals
The pass through terminals are located on the input terminals. These
terminals provide connection points for passing on the incoming O
2
signal to
other devices.
Output (Average) Terminals
These terminals provide a connection point for the average O
2
% 4-20 mA
signals.
Failure / Warning Terminals
These terminals provide connection points for the output signal warning and
failure contacts.
In Cal Terminals
These terminals provide connection points for In Cal signals from the
individual oxygen probes. When a probe is in calibration, it is removed from
any average calculations.
Power Terminals
This terminal provides wire contacts for power distribution in the OxyBalance
system.
OxyBalance operating specifications are listed in Table 1-2.
