969
Input/Output
Correct Source
Sets the corrections for the multiport adapter RFIO 2 port to be applied to the source.
Correct Analyzer
Sets the corrections for the multiport adapter RFIO 2 port to be applied to the analyzer.
Correct Source and Analyzer
Sets the corrections for the multiport adapter RFIO 2 port to be applied to both the source and the analyzer.
Remote Command: [:SENSe]:MPADapter:CORRection:CSET[1]|2|3|4|5|6|7|8|9|1
0|11|12|13|14|15|16:RF:PORT:RFIO2 SOURce |ANALyzer |BOTH
[:SENSe]:MPADapter:CORRection:CSET[1]|2|3|4|5|6|7|8|9|1
0|11|12|13|14|15|16:RF:PORT:RFIO2?
Example: :MPAD:CORR:CSET:RF:PORT:RFIO2 BOTH
Preset: Both
State Saved: Saved in State
Initial S/W Revision: A.10.0
Key Path:
Input/Output, RF Output & Test Set Config, Multiport Adapter,
Corrections, Properties, RF Port, RFIO 2
Example: :MPAD:CORR:CSET[1]|2|3|4|5|6|7|8|9|10|11|12|13|14|15|16:RF:PORT:RFIO2
SOUR
Readback: "Correct Source"
Initial S/W Revision: A.10.0
Key Path:
Input/Output, RF Output & Test Set Config, Multiport Adapter,
Corrections, Properties, RF Port, RFIO 2
Example: :MPAD:CORR:CSET[1]|2|3|4|5|6|7|8|9|10|11|12|13|14|15|16:RF:PORT:RFIO2
ANAL
Readback: "Correct Analyzer"
Initial S/W Revision: A.10.0
Key Path:
Input/Output, RF Output & Test Set Config, Multiport Adapter,
Corrections, Properties, RF Port, RFIO 2
Example: :MPAD:CORR:CSET[1]|2|3|4|5|6|7|8|9|10|11|12|13|14|15|16:RF:PORT:RFIO2
BOTH
Readback: "Correct Source and Analyzer"
Initial S/W Revision: A.10.0
