253
System Functions
System
Initial S/W Revision: Prior to A.02.00
Key Path:
Visual annotation in the Show Alignment Statistics screen
Mode: All
Remote Command: :CALibration:TIME:RFPSelector:LCONducted?
Example: :CAL:TIME:RFPS:LCON?
Notes: Values are the date and time the last successful Align Now, 20 Hz – 30 MHz
was executed. The date is separated from the time by a semi-colon character.
State Saved: No
Key Path:
Visual annotation in the Show Alignment Statistics screen
Mode: All
Remote Command: :CALibration:TEMPerature:RFPSelector:LCONducted?
Example: :CAL:TEMP:RFPS:LCON?
Notes: Value is in degrees Centigrade at which the last successful Align Now, 20 Hz
– 30 MHz was executed.
State Saved: No
Key Path:
Visual annotation in the Show Alignment Statistics screen
Mode: All
Remote Command: :CALibration:TIME:RFPSelector:LRADiated?
Example: :CAL:TIME:RFPS:LRAD?
Notes: Value is the date and time the last successful Align Now, 30 MHz – 3.6 GHz
was executed. The date is separated from the time by a semi-colon character.
State Saved: No
Key Path:
Visual annotation in the Show Alignment Statistics screen
Mode: All
Remote Command: :CALibration:TEMPerature:RFPSelector:LRADiated?
Example: :CAL:TEMP:RFPS:LRAD?
Notes: Value is in degrees Centigrade at which the last successful Align Now, 30
MHz – 3.6 GHz was executed.
State Saved: No
Key Path:
Visual annotation in the Show Alignment Statistics screen
