789
QPSK EVM Measurement
BW
BW
Accesses a menu of functions that enable you to specify and control the Info BW.
Info BW
Activates the Info BW function, which enables you to manually set the information bandwidth of the test
set. This is used to set the hardware filter of the ADC.
Info BW Control
Accesses a menu that enables you to select either A Gaussian or Flat Top filter.
Key Path Front-panel key
Instrument S/W Revision Prior to A.02.00
Remote Command [:SENSe]:EVMQpsk:BANDwidth[:RESolution] <freq>
[:SENSe]:EVMQpsk:BANDwidth[:RESolution]?
Example EVMQ:BAND 1 kHz
EVMQ:BAND?
Key Path
BW
Mode WCDMA, C2K, 1xEVDO
Notes The values shown in this table reflect the conditions after a Mode Preset.
Preset WCDMA: 6 MHz
CDMA1xEVDO, C2K: 1.5MHz
State Saved Saved in instrument state.
Min 1 kHz
Max Hardware Dependent:
RF Input:
No Option = 10 MHz
Option B25 = 25 MHz
Instrument S/W Revision Prior to A.02.00
Key Path
BW
Instrument S/W Revision Prior to A.02.00
