Code Domain
AMPTD Y Scale
AMPTD Y Scale
Accesses a menu of functions that enable you to set the desired vertical scale parameters for the current
measurement.
Numbers and default numbers are independent for each window.
Metrics window and I/Q Symbol Polar Vector and Demod Bits window does not have this menu (Blank
menu).
Y Ref Value
Set the value for the absolute power reference. However, since the Auto Scaling is defaulted to On, this
value is automatically determined by the measurement result. When you set a value manually, Auto
Scaling automatically changes to Off.
Power Graph & Metrics View CDP Window Y Ref Value
Sets the absolute power reference value in the CDP window.
Key Path Front-panel key
Key Path AMPTD Y Scale
Mode cdma2000
Remote Command :DISPlay:CDPower:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]
:RLEVel <real>
:DISPlay:CDPower:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]
:RLEVel?
Example DISP:CDP:VIEW:WIND:TRAC:Y:RLEV –10.0
DISP:CDP:VIEW:WIND:TRAC:Y:RLEV?
Restriction and Notes Unit is sensitive for Meas Type (Abs/Rel) as follows:
Abs: dBm
Rel: dB
Target window to control depends on the SubOpCode.
Dependencies/Couplings See Restriction and Notes
Remote Command Notes Target window to control depends on the SubOpCode.
Preset 0.00
State Saved Saved in instrument state.
Min –250.0
Max 250.0
