About the Test Set
How the Test Set Is Used
GSM/EDGE Mode
(U9071A)
• Transmit Power, also known as Burst Power
• Power Vs. Time, GSM & Edge versions (available to sequencer)
• GMSK Phase & Frequency (available to sequencer)
• Output RF Spectrum, GMSK & EDGE versions (available to sequencer)
• EDGE Error Vector Magnitude (available to sequencer)
cdma2000 Mode
(U9072A)
• Channel Power
• Code Domain
• ACP (available to sequencer)
• Spectrum Emission Mask (available to sequencer)
• Occupied Bandwidth (available to sequencer)
• Modulation Accuracy (available to sequencer)
• QPSK Error Vector Magnitude (available to sequencer)
W-CDMA/HSPA
Mode (U9073A)
• Channel Power
• Adjacent Channel Power (available to sequencer)
• Spectrum Emission Mask (available to sequencer)
• Occupied Bandwidth (available to sequencer)
• Code Domain (available to sequencer)
• Modulation Accuracy (available to sequencer)
• QPSK Error Vector Magnitude (available to sequencer)
• Power Control (available to sequencer)
“WiMAX” Mode
(802.16 OFDMA,
U9075A)
• Channel Power
• Adjacent Channel Power
• Spectrum Emission Mask
• Modulation Analysis
1xEVDO Mode
(U9076A)
• Channel Power
• Reverse-Link Code Domain
• Adjacent Channel Power (available to sequencer)
• Spectrum Emission Mask (available to sequencer)
• Occupied Bandwidth (available to sequencer)
• Reverse-Link Modulation Accuracy (available to sequencer)
Table 2-1 Applications and Measurements in the Test Set
Application Measurement
