702
Code Domain
SPAN X Scale
I/Q Error View Evm Window X Ref Value
Sets the symbol reference value on the horizontal axis in the EVM window of the I/Q Error view.
Code Domain View Symb Power Window X Ref Value
Sets the symbol reference value on the horizontal axis of the symbol power window in the code domain
(Quad view).
State Saved Saved in instrument state.
Min 0
Max 5000000.0
Key Path
Span X Scale
Mode cdma2000
Remote Command :DISPlay:CDPower:VIEW3:WINDow3:TRACe:X[:SCALe]:RLE
Vel <real>
:DISPlay:CDPower:VIEW3:WINDow3:TRACe:X[:SCALe]:RLE
Vel?
Example DISP:CDP:VIEW3:WIND3:TRAC:X:RLEV 10.0
DISP:CDP:VIEW3:WIND3:TRAC:X:RLEV?
Restriction and Notes If the Auto Scaling is set to On, this value is automatically determined
by the measurement result. When you set this value manually, Auto
Scaling automatically changes to Off.
Target window to control depends on the SubOpCode.
Dependencies/Couplings See Restriction and Notes
Remote Command Notes You must be in the cdma2000 mode to use this command. Use
INSTrument:SELect to set the mode.
Preset 0.000
State Saved Saved in instrument state.
Min 0
Max 5000000.0
Key Path
Span X Scale
Mode cdma2000
Remote Command :DISPlay:CDPower:VIEW4:WINDow2:TRACe:X[:SCALe]:RLE
Vel <real>
:DISPlay:CDPower:VIEW4:WINDow2:TRACe:X[:SCALe]:RLE
Vel?
