Configuration Settings 23
35 0000 Not used A/D Output (PORT 1,
Scale 2)
0: For std/normal load
cell (≤ 18 mV)
1: For abnormal load
cell with too large
offset (> 18mV)
A/D Filtering (PORT 1, Scale 2)
00: Normal
01: Protect from small vibration/fast change in
display
10: Protect from medium vibration
11: Protect from large vibration, slow change in
display
36 __00 Minimum Display (PORT 2, Scale 2 or 3)
MUST BE SET PRIOR TO CALIBRATION!
00: 2 01: 1
10: 5 11: 10
A/D Filtering (PORT 2, Scale 2 or 3)
00: Normal
01: Protect from small vibration/fast change in
display
10: Protect from medium vibration
11: Protect from large vibration, slow change in
display
37 1001 Load Cell Sensitivity Selection (mV/V)—PORT 2, Scale 2 or 3
Load cell sensitivity is automatically set at calibration. Manual adjustments can be made to reduce noise.
Spec
Min Max
0000: 3.46 4.00
0001: 3.00 3.46
0010: 2.59 3.00
0011: 2.25 2.59
Spec
Min Max
0100: 1.95 2.25
0101: 1.69 1.95
0110: 1.46 1.69
0111: 1.27 1.46
Spec
Min Max
1000: 1.09 1.27
1001: 0.95 1.09
1010: 0.82 0.95
1011: 0.71 0.82
Spec
Min Max
1100: 0.61 0.71
1101: 0.53 0.91
1110: 0.46 0.53
1111: 0.40 0.46
38 0010 A/D Output (Scale 3)
0: For std/normal load
cell (≤ 18 mV)
1: For abnormal load
cell with too large
offset (> 18mV)
Digital Tare with Weight
on Scale
0: Yes
1: No
Internal Count
0: 500,000
1: 1,000,000
Stability Check When
Changing Scale
0: Yes
1: No
39 0010 Set SPEC 39 to 0010
SPEC Default Bit 3 Bit 2 Bit 1 Bit 0
Table 4-2. DC-190 142 Settings (Continued)
