SECTION 6—OPERATING INSTRUCTIONS

Invacare SOLO

2

™ 26 Part No 1156872

Breath Detect Indication

(PulseModeOnly)TheGREENindicatorlightwillblinkoffeachtimean

inhalationisdetectedandthetransportableoxygenconcentrator outputsa

measuredpulseofoxygen.

Audible Alarm

Thetransportableoxygenconcentr atorisequipped withanaudiblealarm.

Theaudiblealarmwillactivatedinconj unctionwith IndicatorsandLCD

Displayto

annunciateAlarmsandWarnings.

Thetransportableoxygenconcentr atorwillalsoissueasteadybeepwhen

allpowersourcesareremoved.Th ebeepin gwill stop after10‐20 minutesor

onceapo wersourceisconnected.

Thetransportableoxygenconcentr atorwillbrieflyturnonallthreelights

andtheLCDdisplayand

checkforstuckbuttonsuponpow erup.Itwill

thenoutputabriefaudiblebeeptoindicate theunitisoperational.

Control/Adjustment Buttons

TherearefourbuttonslocatedsurroundingtheLCDdisplay.Th ey are used

toturntheuniton/off,toproceedtothenextscreen,toselectandhighlight

adjustablesettingsandtoadjustthosesettings.

On/Off Button

Toturnthetransportableoxygenconcentratoronoroff,pressandholdthe

On/Offbuttonfor a

periodof2‐3seconds,nottoexceed5seconds.Releasing

thebuttontoosoonwillnotallowtheunittodo either.Ifthebuttonisheld

toolongwhenturningontheunit,theStuckButtonalarmcouldbe

activated.

Mode/Return/Highlight Button

Pressingbuttonfor1‐2secondsin the

Standbyscreen(FIGURE6.5on

page 27)willswitchtoNormalOperatingscreen(FIGURE6.6on page 27).

Pressingthisbuttonfor1secondintheNormalOperating screenwilltoggle

betweenthe continuousandpulsemodes.

Pressingthisbuttonfor2‐3secondsintheNormalOperatingscreenwill

displaytheLCD

Adjustments creen.In theLCDAdjustmentscreen

pressingthisbuttonfor1secondwillswitchcolumnsonthescreen.Tosave

changesandexittheLCDadjustmentscreenthehighlightbarneedsto be

positionedintheleftcolumn,thenpre s sthisbuttonfo r2‐3secondstoreturn

to

theNormalOperatingscreen.Ifthescreenswitches withoutpressing and

holdingthebuttonfor2‐3secondsthechangesmadeintheLCD

Adjustmentscreenwillnotbesaved.

Increase and Decrease Buttons

Whenthehi ghlightbarisonthesettingname,thesebuttonsareusedto

selectthenextsettinginthelist.

Whenthehighlightba r isonthesetting

value,thesebuttonswillchange thevaluetothenextvalueavailable.
