SECTION 6—OPERATING INSTRUCTIONS

Part No 1156872 25 Invacare SOLO

2

™

FIGURE 6.4 Humidifier Attachment

Transportable Oxygen Concentrator Front

Panel and LCD Display

NOTE:Forthisprocedure,refertoFIGURE6.9onpage 30.

ThefrontpanelconsistsofLEDindicators(red,yellowandgreen),

control/adjustmentbuttonsandaLCDdisplay.

Indicators and Audible Alarm

TherearethreeindicatorLEDslocatedjustabovetheLCDdisplay‐green,

yellowandred.Theindicatorscoul dbeonsteadyorblinkingatdifferent

ratesdependingonthespecific op eratingcondition,includinganywarning

oralarm.

NOTE:Fordetailedexplanationanddescriptionsofthewarningsandalarms,see

Warningsand

Alarmsonpage 37orTroubleshootingonpage 35.

Green Indicator

TheGreenindicatorisonwhentheunitisoperatingnormallyand

providinggood(>85%)oxygenpurity.

Yellow Indicator

TheYellowindicatoristypicallyon,orblinking,whenthereisawarningor

non‐optimal conditionpresent.Thetransportableoxygenconcentrator

couldstillbe operating,butsomeuseractionmay 

berequiredtoreturnto

normaloperation.

Red Indicator

TheRedindicatoris typicallylit,orflashing,whenthereisanalarmthat

requirestheimmediateattentionoftheuser.Alarmstypicallyresultinthe

unitstoppingwithnodeliveryofoxygen.

Humidifier

Bottle

Humidifier

Bottle Adapter

Humidifier

Bottle

DETAIL “A”

DETAIL “B”

To Oxygen Outlet

Connector (Not Shown)

Humidifier

Bottle

Adapter

Patient

Cannula
